How to Set Up PlotSquared for Creative Plots

Creative plot servers remain one of the most popular Minecraft server types. Players claim a fixed-size area, build whatever they want, and visit each other's creations. PlotSquared is the dominant plugin for this, it generates the grid world, handles claim logic, manages permissions per plot, and supports merging, ratings, and flags. This guide covers the full PlotSquared Minecraft setup process from installation to a production-ready creative server.

Requirements

• Paper 1.21+ (or any Paper fork like Purpur).
• FastAsyncWorldEdit (FAWE), PlotSquared requires it for schematic pasting and plot clearing. See How to Set Up WorldEdit.
• Java 21 or newer.
• At least 4 GB of RAM allocated to the server (plot worlds with many claimed plots consume memory).

Installation

1. Download PlotSquared from SpigotMC or the IntellectualSites GitHub releases.
2. Place the JAR in your plugins/ folder.
3. Restart the server. PlotSquared generates its config files on first boot.
4. Verify with /plot help in-game.

Creating the plot world

PlotSquared generates its own world using a custom chunk generator. Create it with:

/plot setup

The setup wizard walks you through:

1. World name, keep it simple: plots or creative.
2. Generator, choose PlotSquared.
3. Plot type, normal for standard flat plots.
4. Plot size, the width/length of each plot in blocks. Common values: 42 for small servers, 64 for medium, 128 for large. You cannot change this after generation without resetting the world.
5. Road width, space between plots. 7 or 9 blocks is standard. Wider roads feel more open but waste space.
6. Road height, the Y level of the road surface. 64 is default.
7. Wall and border blocks, the materials used for the plot border. Stone slab walls with bedrock borders are a clean default.
8. Floor block, the surface of each plot. Grass block is classic; white concrete works for modern themes.
9. Fill block, what sits below the floor. Dirt for grass floors, stone for concrete.

After confirming, PlotSquared generates the world and teleports you to it.

Configuration deep dive

All settings live in plugins/PlotSquared/config/. The key files:

settings.yml

plots:
  max_plots: 4          # max plots per player (override with perms)
  claim:
    max_auto_area: 4    # max plots claimable with /plot auto
  schematic_on_claim: false  # paste a schematic when a plot is claimed

Adjust max_plots based on your server's capacity. Donors can get higher limits via the plots.plot.# permission node, for example, plots.plot.10 allows 10 plots.

worlds.yml

Per-world overrides for plot sizes, road materials, and flags. If you skipped the setup wizard or want to tweak values, edit this file directly and restart.

Essential commands

Command	Description
/plot claim	Claim the plot you are standing on
/plot auto	Auto-claim the next available plot
/plot home	Teleport to your plot
/plot visit <player>	Visit another player's plot
/plot merge	Merge adjacent plots you own
/plot trust <player>	Give full build access
/plot add <player>	Allow build access only while you are online
/plot deny <player>	Ban a player from your plot
/plot clear	Reset the plot to its default state
/plot delete	Unclaim and clear the plot
/plot flag set <flag> <value>	Set a plot flag

Plot flags

Flags control per-plot behavior. The most useful for a creative server:

• /plot flag set time 6000, locks the plot to noon for building visibility.
• /plot flag set weather clear, no rain on the plot.
• /plot flag set fly true, allows flight on the plot (essential for building).
• /plot flag set mob-place true, allows placing mobs for decoration.
• /plot flag set gamemode creative, forces creative mode on the plot.
• /plot flag set music music_disc_cat, plays background music.

Server-wide default flags are set in settings.yml under flags.default. Setting fly and gamemode defaults there saves every player from running the commands individually.

Permissions setup

PlotSquared permissions integrate with LuckPerms. Key nodes:

plots.use          # basic plot commands
plots.claim        # ability to claim plots
plots.auto         # /plot auto
plots.merge        # merge adjacent plots
plots.plot.4       # max 4 plots
plots.admin        # admin override commands

For a clean PlotSquared Minecraft setup, create a "Builder" group in LuckPerms with the basic nodes and a "Donor" group with higher plot limits and merge access. See permission inheritance for organizing groups efficiently.

Customizing roads and borders

The default gray roads are functional but bland. Customize them by editing worlds.yml or using road schematics. PlotSquared supports pasting a schematic for the road layer, design a decorative road in WorldEdit, save it as a schematic, and reference it in the config. This is how servers achieve patterned roads, streetlights, and garden borders.

Performance and maintenance

• Plot expiry, enable automatic plot clearing for inactive players to reclaim space. Configure in settings.yml under clear.auto.
• Chunk limits, PlotSquared worlds can have thousands of claimed plots. Each claimed plot loads chunks. Set view-distance lower for the plot world in server.properties or per-world with a view-distance plugin.
• Backups, PlotSquared stores plot metadata in a database (SQLite by default, MySQL supported). Back up both the world folder and the database file.

A solid PlotSquared Minecraft setup gives players a creative outlet with zero risk to your main survival world, and the plugin's permission system keeps everything organized without manual intervention.
